Blister Packing machine is designed as CE certifed. The machine is modular design, making simple provision for adding future options if needed. There's no waste when change speed in a wide range or when restart machine after stop. Ajustment is allowed during operation. The noise is low. Thanks to quick clamp, few number of size parts, small & compact change part makes quick changeover.

The machine works on intermittent principle, plate sealing, with foil supply station - forming station - feeding - perforation / embossing - cutting.

Control is by PLC S7 and user- friendly Touch screen, or Industrial PC as option.

The software is 21 CFR Part 11 (FDA) compliance.

Specifications

Blister packaging machine B-600 for productivity up to 600 blisters / minute. The machine is suitable for products that need high productivity.

Blister Packing machine B-600 has option to fully covered with canopy from foil supply, forming area, feeding area until sealing, finished cut product, suitable for containment purpose and comply FDA requirements.

Servo- driven technology for accurate indexing via digital setting.

Detect the Alu cold foil down to 25 μm, using infrared ray. Blister with hole will not be fed (by matrix feeder) and to be auto rejected.

The fill control is inspected by different options of color camera.
Camera will detect the mis-filled blister, broken table, wrong shape product, wrong color tablet, chipped tablet, empty blister ,... Robot arm to "pick & place" good blister by Servo drive to place on discharge conveyor. Defective blister will be strapped down into reject container.

There're different types of auto feeder to be suitable for many different shapes of products.

Blister packaging machine B-300 productivity is max. 300 blisters /minute.

Blister Packing machine B-300 is fully covered with canopy from foil supply, forming area, feeding area until sealing, finished cut product, suitable for containment purpose and comply FDA requirements.

Less noise, only 72 dB.

Adjustment is allowed during operation.

Quick changeover thanks to quick clamp, compact format and few number of change parts.

Servo- driven technology for accurate indexing via digital setting.

Detect the Alu cold foil down to 25 μm, using infrared ray. Blister with hole will not be fed (by matrix feeder) and to be auto rejected.

Online printing helps to print barcode, expiry date, manufacturing date on line,… on lid foil of blister.

Besides, the Blister can be equipped with Optical Variable data Verification system with Character Recognition (OCV/OCR).

It can be connected to the Automatic Cartoning machine to make a fully automatic Blister-Cartoning line.

Blister packaging machine CP-250 for productivity up to 300 blisters / minute. The machine is suitable for packing blister PVC/Alu, PVDC/Alu, Alu/Alu, for tablet, capsule, vial, ampoule, syringe,...

Compact mold, quick changeover without tools.

Servo- driven technology for accurate indexing via digital setting.

The fill control is inspected by different options of color camera. Robot arm will pick qualified blister and placed on discharge conveyor, defective blister will be strapped down into reject container.

Pin hole detecter can detect the Alu cold foil down to 25 µm, using infared ray.

It is suitable for many different methods of automatic feeding depending on specific product such as Brush box feeder, Matrix feeder, Vibration disk & Feeding rail, Roller feeder, Auto feeder for vial/ampoule/syringe,...

It can be connected to the Automatic Cartoning machine to make a fully automatic Blister-Cartoning line.

Blister packaging machine CP-160 gives productivity max. 200 blisters / minute.

Compact mold, quick changeover without tools.

Blister machine model CP-160 is suitable for small scale production plants that do not require a high level of automation.
